Mechatronics MXF50290H12B-R 354mm x 70mm x 70mm DC Cross Flow Fan

MXF50290H_photo
Check Stock Request Quote

Specifications

Model Number MXF50290H12B-R
Series MXF50290H
Product Type DC Cross Flow Fans
Dimensions 354mm x 70mm x 70mm
13.94in x 2.76in x 2.76in
Rated Voltage 12VDC
Weight 0.63 kg
Frame Construction Steel
Impeller Construction Aluminum
Motor Type Brushless DC
Airflow Tangential
Motor Protection Reverse polarity protection, Locked rotor protection
Storage Temp -40°C ~+70°C
Operating Temp -20°C ~+70°C
Insulation Class Class A

Available Options

Bearing Options Ball bearing
Connection Options Lead wires
Protection Options Conformal coating
Additional Options Tachometer Output, PWM Speed Control
MXF50290H_drawing
STATIC PRESSURE (IN. OF WATER) AIR FLOW (CFM) 0 0 2 0 4 6080100120 0.04 0.08 0.12 0.20 0.16 H

Models

Input Power Rated Current Speed Air Volume Max Static Pressure (H2O) Sound Noise
W A RPM m3/min CFM mm/H2O in/H2O dBA
4.92 0.41 2,100 3.20 112.9 4.32 0.17 45
